iSCSI Cake Features
- iSCSI Compatibility: Supports iSCSI initiators on Windows, Linux, and Solaris.
- OS Compatibility: Supports all 32bit/64bit Windows 2000/XP/2003/VISTA and later operating systems.
- 64bit Addressing: Breaks through the 2TB limitation.
- Cluster Sharing: Shares storage among cluster nodes.
- VMWare Compatibility: Exports VMWare VMDK disk file as target disk.
- ISO Support: Simulates virtual CDROM drive.
- Port Forwarding: Provides service while under the protection of firewall.
- High IO performance: Server cache with per-client cache together delivers high IO efficiency.
- Easy to Manage: Windows based GUI can be installed on any computers to manage iSCSI server.
- COW protection: Protects server data from unauthorized client.
iSCSI Cake Specification
| Server OS |
Windows 2000/XP/2003/VISTA/2008 (x86/x64) |
| Client OS |
Windows/Linux/Solaris |
| Max capacity |
4 PB |
| Max LUNs |
16 |
| Source storage |
Disk/Partition/VMWare File/ISO File |
| Boot from iSCSI |
Windows/Linux |
| Network |
Ethernet/Wan (Support port mapping) |
| Cache |
Server cache and per-client cache |
| Security |
CHAP |
| Management |
Local/Remote |
| iSCSI protocol |
iSCSI standard 1.0 |
 | |
Server System Requirements
| < 60 clients
|
- CPU: 1.7G
- RAM:512M
- Disk: 1 SATA-2 primary storage, 40G secondary storage working dir
- MainBoard: With SATA-2 support
- Network: 100Mb Ethernet
| | 60-120 clients |
- CPU: 2.0G
- RAM: 1G
- Disk: 2 SATA-2 RAID primary storage, 80G secondary storage working dir
- MainBoard: With SATA-2 support
- Network: 100Mb Ethernet with 1 GBE port
| | 120-200 clients |
- CPU: 2.8G
- RAM: 1.5G
- Disk: 3-4 SATA-2 RAID primary storage, 2 SATA RAID secondary storage working dir
- MainBoard: With RAID support
- Network: GBE (2GBE NIC for over 150 clients)
| | > 200 clients |
- CPU: 3.0G
- RAM: 2.0G
- Disk: 3-4 SATA-2 RAID primary storage, 2 SATA RAID secondary storage working dir
- MainBoard: Professional 64bit server mainboard
- Network: Multiple GBE NICs
|
|
 |
|
